DRIVECARD Hard Disk/Floppy Controller Settings and Configuration
MOUNTAIN NETWORK SOLUTIONS, INC.
DRIVECARD
Data bus: 8-bit, ISA
Size: Full-length, full-height card
Hard drives supported: Two MFM ST506/412 drives
Floppy drives supported: None
USER CONFIGURABLE SETTINGS | |||
Function | Location | Setting | |
| » | BIOS enabled | JP1/jumper 7 | open |
BIOS disabled | JP1/jumper 7 | closed | |
| » | BIOS address is CA000h | JP1/jumper 8 | closed |
BIOS address is C8000h | JP1/jumper 8 | open | |
DRIVE TYPE | ||||||
Drive 1 | Drive 0 | |||||
Type | Hds | Cyls | JP1/jumper 1 | JP1/jumper 2 | JP1/jumper 3 | JP1/jumper 4 |
10 MB | 4 | 306 | open | open | open | open |
20 MB | 4 | 615 | closed | open | closed | open |
40 MB | 8 | 615 | open | closed | open | closed |
42 MB | 5 | 977 | closed | closed | closed | closed |
I/O PORT ADDRESS | |||
Address | JP1/jumper 5 | JP1/jumper 6 | |
| » | 324h | closed | open |
320h | open | open | |
328h | open | closed | |
32Ch | closed | closed | |
DRIVECARD CONFIGURATION | ||
Setting | Jumper JP9 | Jumper JP10 |
DriveCard is first drive* | pins 1 & 2 closed | pins 1 & 2 closed |
DriveCard is second drive | pins 2 & 3 closed | pins 2 & 3 closed |
Note:* When another hard disk uses its own controller, this setting stays the same and the DriveCard becomes the second drive | ||
.
